LOA - Length Over All (Integrated swim platform to Bowsprit) ........................................ 73' 6"
..........USCG registration (Integrated swim platform) .................................................................. 68' 6"
..........Length on deck ............................................................................................................... 65' 0"
..........LWL............................................................................................................................... 58' 7"
Maximum Beam .................................................................................................... ......... 18' 8"
Condition at Port Departure (100% stores) - Displacement.....................approx. ............. 58 Long Tons
..........GMT.................................................................................................. ..........................2.871 Ft
..........VCG ............................................................................................................................8.6 Ft
..........LCG (+ fwd)................................................................................................................-3.781 Ft
..........Draft ............................................................................................................................5' 5 ¼"
Condition at Port Arrival (10% stores) - Displacement ..............................approx. ............ 51 Long Tons
..........GMT.................................................................................................. .........................3.431 Ft
..........VCG ................................................................................................... .......................8.844 Ft
..........LCG (+ fwd)...............................................................................................................-3.212 Ft
..........Draft .................................................................................................. ........................5' 1 7/8"
Water Capacity ...........................................................................................approx. ............ 450 Gal. US
..........Water Tank........................................................................................ ........................ 427.2 Gal. US
..........Hot Water Heater .............................................................................. ........................ 30 Gal. US
Waste Tank Capacity ..................................................................................approx. ............ 100 Gal. US
Fresh Oil Tank Capacity ...................................................................................................... 22 Gal. US
Waste Oil Tank Capacity ..................................................................................................... 22 Gal. US
Gasoline Fuel Capacity........................................................................................................ 26.2 Gal. US
Diesel Fuel Capacity...................................................................................approx. ............ 2,200 Gal. US
..........Saddle tank (Port)....................................................................................................... 902.3 Gal. US
..........Saddle tank (Starboard) .............................................................................................. 902.3 Gal. US
..........Aft tank (Under master stateroom bed) ...................................................................... 392.6 Gal. US
Height above Water Line, with antennas does not exceed................................................... 29' 6"
Accommodations - Staterooms ............................................................................................ 5
..........Sleeping Capacity (berths) ................................................................ ........................ 11
..........Heads................................................................................................. ........................ 4
Engines - Alaska Diesel .......................................................................................................
..........Main Engines - Lugger L-6140A l (2) - Hours: 1/17=@ 11,000............................... 600 HP each
..........Main Engines - Serial Numbers.................................................................................1401-0871, 1401-0872
..........Gensets - Northern Lights by Alaska Diesel (2).........................................................8 kW (13.5 HP) & 20 kW(32 HP)
..........Genset - 8 kW Serial Number - Hours: 1/17=@ 3700 .............................................7532-7044 (M753)
..........Genset - 20 kW Serial Number - Hours: 1/17=@ 2100 ...........................................9642-9031 (M964-20)
Vessel USCG Documentation Number................................................................................972716
Vessel WA State Registration Number................................................................................WN3255RB
Vessel Hull Identification Number .......................................................................................CEL65001D191
Date of delivery ...................................................................................................................July 12, 1991
Wooldridge 1994 15' “Alaskan” shore boat WA State Registration Number ......................WN 8176RC
Wooldridge 1994 15' “Alaskan” shore boat Hull Identification Number ..............................WLG15232D494

GENERAL

Built under the personal supervision of Forbes Cooper who built over 4,000 yachts of various types and shapes
during his career.
Vessel has a detailed 50+ page Operations & Equipment Manual giving operating instructions for all major vessel functions.
..........In addition, there is a full electrical wiring manual showing electrical layouts, plus manuals and/or parts diagrams for each piece of ..........equipment onboard.
As of the fall of 2016, vessel has logged over 90,000 miles in almost 11,000 hours of operation including 23 trips toSoutheastt
..........Alaska and 20 trips across the Gulf of Alaska to South Central Alaska including circumnavigation of Kodiak Island and
..........exploration of the Alaska Peninsula. With her built-in redundancy, the Inside Passage has never had to layover a single
..........day because of operational problems such as might be caused by mechanical, electrical or structural breakdowns or failures.

HULL, SUPERSTRUCTURE, AND DECKS

Hull is hand-laid gelcoated fiberglass, sandwich cored with a minimum of 1" vacuum bagged Airex core, using an ISO resin on
..........the outside lay-up to give better protection from water penetration. The hull is stiffened using Top Hat fiberglass stiffeners
..........and foam cored bulkheading in the main full bulkheads. The hull is coated outside below the waterline with two
..........coats of an epoxy barrier coat and then covered with Woolsey Neptune Premium bottom paint.
The forward part of the hull from the stabilizers forward is double bottomed with double Airex plus a foam core. This gives
..........additional safety protection and virtually eliminates the possibility of interior condensation.
The decks and entire superstructure and is hand-laid gelcoated fiberglass sandwich cored with Divinicell foam with the house
..........sides using 1.5" thick foam. 20 lb foam is used in structural areas such as under the decks.
Structural bulkheads are 1" thick single foam cored Divinicell throughout except for engine rooms which are 2" double thickness.

ENGINE ROOM

Engine room bulkheads fore and aft are doubled (see above) and the engine room issheeted, along with the deck head, with Vibrasonic
..........composite insulation. Engine room ceiling has 6" of fiberglass insulation above ½" plywood and the Vibrasonic
..........composite insulation. Total floor thickness including flooring covering above is approximately 8".
The finish of the non-insulated areas is gelcoated white, and the floor is covered with removable aluminum checker plate floor-boards.
The engine room is vented with manually closable vents.
Engine room has workbench with aluminum top, ½ HP 6" double wheel bench grinder, and vise, wall mounted tool chest, fresh
.......... water outlet, and four 120v receptacles. Extra filters and belts are carried onboard.
Engine room lighting 4 - 120v 2 tube 40 watt fluorescent lights plus Two 120v single tube 40 watt fluorescent lights plus six
.......... 12v incandescent lights in explosion proof fixtures.
Two 9" x 22" Freeman Marine elliptical portlights (and alternative escape hatches) with screens.
Access through insulated aluminum watertight door with view window located behind decorative wood panel door.

MAIN ENGINES

Main power is supplied by two (2) 600 HP Alaska Diesel "Lugger" L-6140A diesel engines equipped with Twin disc
.......... MG5111A gears in 1.95:1 ratio.
Propellers are four-bladed workhorse 34" x 29" Ni-Bral by Federal Propellers of Michigan. A spare set of 34" x 26" Ni-Bral
..........props with appropriate tools and prop puller for changing props are carried onboard. All that is needed is a tidal grid or
..........marine ways. Hub is 3 ½" diameter with ½" threaded rod (American standard). Prop puller hole is 3 7/16" apart on cen-
..........ter and rods are 6" long.
The water-cooled shafts (3") and the struts are 316 stainless steel. Shaft legs are fitted with water cooled bearings.
Engines have underwater exhaust while underway with bypass system in sponson for idling/low RPM conditions.
Spurs (high strength stainless steel line cutters) are fitted on propeller shafts to protect against propeller fouling from loose
.......... lines or nets.
Fresh water/antifreeze cooling through heat exchangers, using Groco 2" raw water strainers connected to the hull with 2"
..........bronze through hull fittings & bronze valves.
12v engine starting (as confirmed by engine manufacturer as being used in 70% of all similar installations) with starting battery
..........bank of 2 HD 8-D starting batteries charged by it's own separate battery charger plus as well as a separate 72 amp 12v alt-
..........ernator on the port engine. Interconnect between starting batteries and main battery bank for emergency additional cranking power, if
..........needed, is located in pilothouse, plus interconnect above starting battery bank and genset starting battery for backup.
..........The starting batteries are located under the engine room floorboards between the main engines. There are separate battery shutoffs on
..........each main engine.
Pilothouse has standard "Blue Line" instrument panels plus Lugger auxiliary panel.
Fly bridge has Lugger flybridge panels. Engine room has Lugger Local Control instrument panels.
Lugger expansion tank sight glasses are remote mounted.
Lugger alarm system covers engine water temperature, engine oil pressure, gear oil pressure, engine exhaust temperature, etc.
There is an oil changing system providing the capacity for a single change for both main engines including separate 22 gallon
..........tanks for fresh (port side) & waste oil (starboard side). Operator has the choice of direct discharge of waste oil from en
..........gines into removable containers, or into the waste oil storage tank for future removal. Hoses on oil change system have
..........quick release connectors.
Floscan Cruisemaster fuel monitoring system on starboard engine calculates the net flow .

MECHANICAL

All through-hull fittings are bronze. Check valves are fitted to all bilge overboard pumps.
25 HP Wesmar T25 hydraulic bow thruster (using 90 weight gear oil) with Cessna pump upgrade operated from pilothouse, fly
..........bridge, and ZF Mathers handheld dual controls.
Engine driven hydraulic system to power anchor windlass, bow thruster, engine driven bilge pump, and crane. The system is driven
..........off two fresh water cooled hydraulic pumps on each engine for redundancy and is designed to operate these pieces of equipment with
..........engines at idle.
Naiad model 252 hydraulic stabilizers with 5.5 square foot fins driven off either of dual hydraulic pumps on both engines.
Bracket/pin at rudder mechanism to hold rudders in center position in case of loss of steering control

GENERATOR SETS

8 kW Northern Lights fresh water-cooled generator (M753) with sound shield and series 1B panel in engine room. Series 3
..........control panel in pilothouse, and Series 1 panel (start/shutoff only) located at cabinet at port side of bed in master stateroom.
20 kW 1800 RPM Alaska Diesel "Northern Lights" fresh water-cooled generator (M854) with sound shield and hydroelastic mounts and
..........series 1B panel in engine room. Series 3 control panel in pilothouse.
20 kW generator will run all existing equipment onboard simultaneously. Electrical system is set up so both gensets can be run at the same
..........time and handle separate loads. Thus, capacity is designed into the system for the future addition of airconditioning, if desired.
12v 4D battery for generator starting. Crossover switch with main engine battery starting bank for emergency additional cranking power if
..........needed.
Fresh water cooling through heat exchangers using Groco raw water strainers connected with bronze through hull fittings & bronze valves.
The exhaust to each gensets has a water separator so that water is exited under the waterline to reduce sound level. The 20 kW genset
..........exhausts to starboard amidships and the 8 kW genset through the rear of the swim platform.

ENGINE FUEL SYSTEM

Three fuel tanks of ¼" aluminum. Tanks have inspection ports. The two saddle tanks are 902.3 gallons each. The stern tank
..........has 392.6 gallons. In compliance with American Bureau of Shipping standards, tanks have no drains or sight gauges.
..........All fuel is removed and added through the top of the tank.
Separate supply and return fuel manifolds for both main engines & gensets with crossover valves. 12v fuel transfer pump with
..........timer and resettable counter plus back up manual hand pump allows transfer of fuel between all three tanks.
Each main engine and the 20 kW generator have double Racor fuel filters. The main engines have double vacuum gauges.
..........The 8 kW genset has a single Racor fuel filter.
VDO gauges readable from pilothouse on all tanks including waste tank. Additional VDO gauge to stern fuel tank is located in
..........engine room.
Direct drop of fuel from fills to main tanks.

FRESH WATER SYSTEM

Fresh water tank of ¼" aluminum - 156 #5052 alloy w/VDO gauge in pilothouse. Capacity is 427.2 US gallons
Paragon 12v Senior pressure water system with two pumps in series distributed throughout using 3/4" tubing. Pumps are located
..........in engine room to reduce noise. Five-gallon pressure accumulator tank on water system.
Hot water provided by Torrid 30 US gallons tank with engine heat exchanger, hot water heating system heat exchanger & 120v
..........electric element.
800 GPD (33 GPH) modular Sea Recovery model SRC 800 AM reverse osmosis water maker (serial number AMO 7855 0890)
..........with full set of spare filters and parts. Remote set of watermaker controls in pilothouse. Water passes through raw water
..........strainer, plankton filter, commercial sized primary sediment filter, oil/water separator, high-pressure osmosis membranes,
..........final charcoal filter, and ultraviolet sterilizer. Fresh water flushing system allows owner to purge salt water from system when unit is to
..........be unused for extended periods.
Ametek PVHCL double canister (sediment filter and taste/odor filter) water filtration system with several sets of spare filters.
Additional fresh water outlets in engine room, lounge deck, and bow wash down compartment.

SEA WATER SYSTEM

X-caliber salt water pressure sea water system single pump with outlets in bow wash down compartment and aft deck under
..........sink. Three gallon pressure accumulator tank on sea water system. This is also an alternate backup source of water for
..........toilets.

WASTE MANAGEMENT SYSTEM

Holding tank of 100 US gallons connected to Jabsco macerator pump with mechanical timer control located in pilothouse.
..........Tank is made of polyethylene. The holding tank has a "Y" exit valves for either through hull overboard discharge or to a
..........sanitary waste station.
Vacuflush toilet flushing system uses individual pump model # S12 for port guest and master stateroom heads. Day head and
..........starboard guest head share a commercial pump model # B12. Individual shutoff switches in each head.
All heads have "Y" exit valves and through hull fittings for alternate of holding tank or direct overboard discharge.

BILGES

The bilges are divided into four sections watertight below waterline. The most forward bilge has a totally sealed collision
..........bulkhead accessible by watertight hatch with ladder access. This forward watertight storage area has tie down rings and
..........shelves for storage of lightweight items.
A master bilge pump system is hydraulically driven off the main engine and connected to each of the watertight sections. It is
..........operable from either the engine room or pilothouse
In addition, there are four (4) other bilge pumps, #1500 Rule or larger, for each watertight bilge section. Each has a resettable
..........counter with display in pilothouse.
High water alarms in each bilge. Alarm panel in pilothouse gives visual and audible indication when bilge pumps are running,
..........and/or when high water alarms are activated.
Common gray water gravity drain system for sinks & showers. Gray water tanks fore and aft with Rule 2000 GPH pumps.

ELECTRICAL SYSTEM

Four AC power circuit breaker banks. One runs items that are 120/240v loads, one runs items that are 120v loads, and the
..........other two are served alternatively by an auto transfer switch by inverters or by 120v power.
Two house domestic and instrument 12v power banks. Each separate bank consists of six 12v 8-D deep cycle sealed AGM
..........gelcell batteries with 1350 amp/hour reserve. Each bank is charged through the 140 amp alternators and the two Xantrex
..........Prosine PS3.0 120 amp chargers described below which provide automatic three-stage charging and include battery temperature
..........sensors. The chargers have adjustable maximum AC input current to protect against nuisance tripping of shore
..........power or generator AC circuit breakers. Original 1991 batteries were replaced in 2005-2006 and again for the 2010 season.
The two house battery banks have a cross over switch in case one of the inverter/battery chargers goes out, plus a spring loaded
..........cross over switch located in the pilothouse to the starting battery bank if an additional starting boost should ever be
..........needed. All batteries have covers and the non gel cell batteries are housed in leak proof battery cases with covers.
Two 3000 watt Xantrex Prosine PS3.0 Inverter/Chargers are connected to the electrical distribution system with automatic
..........transfer switches. Each Inverter/Charger has a surge rating of 4000Watts and a peak output current of 50 Amps. There
..........are remote panels in the pilothouse that display battery levels and the rate of charge/discharge of the battery banks.
From the pilothouse, the operator chooses whether each of the two inverter banks is to be served by shore power, generator
..........power, or from either inverter (redundancy). In addition, each charger can charge both battery banks through the crossover
..........switch between the two main battery banks (further redundancy). All equipment onboard will operate off inverters
..........except washer, dryer, water maker, & dishwasher.
Two Leece-Neville (Model 8HA2070VB) 140 amp engine driven 14v alternators for two main battery banks plus one 72 amp
12v alternator for the starting battery bank. The generators charge their respective starting batteries.
There are two separate battery chargers with one serving the main engine starting battery bank and the other serving the generator
..........starting battery.
Two Ample Power Company Power Management Systems (PMS) give the operator instant readout on all key AC & DC electrical
..........components including AC voltage, AC current, AC frequency, DC voltage on main & starting battery banks, DC
..........current, DC charging current, DC battery temperature, alarms for DC battery temperature, battery charging & discharge
..........alarms (both banks), DC amp hours consumed, DC amp hours remaining, and time remaining in battery banks at current
..........rate of discharge.
All grounds throughout the boat are connected to 2" copper straps running from the bow aft to both port and starboard. All
..........through-hull fittings and metal under the waterline are bonded to the grounding system. Two large zincs on transom.
..........Shafts have stainless steel brushes.
Shore power connections provided on both starboard (50 amp 240 volt-aft) and port (50 amp 120 volt-forward) sides. Isolation
..........transformer converts 120-volt shore connection to 240-volt power and isolates electrical system from shore power system.
Battery isolator(s).
The engine electrical system is coded and/or identified, and an electrical manual including diagrams and drawings is provided
..........thus making future additions and/or troubleshooting easier.

HEATING & COOLING SYSTEM

Webasto DBW 300 diesel fired hot water heating system with separate fuel filter provides heat to all areas including heads.
..........Thermostatically controlled two speed blowers in each stateroom/head with unit located at base of bed to serve both
..........stateroom and head excepting bow stateroom and day head which have separate thermostats and blowers. Fin only type
..........radiator for captain's stateroom. Thermostatically controlled two speed blowers in salon (2), and pilothouse. Vessel has
..........eight separate thermostatically controlled heating zones.
Three-speed blower tied to hot water heating system located to service windshields in pilothouse.
Four 1000 watt fan driven electric space heaters with remote thermostatic controls provide additional/backup heating and are
..........used during inactive or storage periods. One each located in pilothouse, salon, master stateroom, and forward lower
..........companionway.

PILOT HOUSE
Helm with full instrumentation - by engine manufacturer (see Engines).
Kobelt hydraulic driven power steering using two engine driven Spencer pumps for redundancy and single engine operation.
ZF Mathers single lever dual electronic controls including built-in engine sychronizers.
ZF Mathers handheld dual control includes bow thruster interfaces and built-in engine synchronizers. Extension cord allows
..........operator to work from bow pulpit (for anchoring) to swim platform (for docking). Handheld control is stored ready to go
..........but out of sight until needed.
Five articulated pantograph windshield wipers (3 @ 28", 2 @ 24") and fresh water window washers for all five forward windows
..........with 2 set speeds plus a wide range of timer delays for intermittent wiper use.
Two movable and adjustable leather covered helm seats are positioned so that both have easy access to autopilot, shift/power
..........and other essential control systems.

PILOTHOUSE ELECTRONICS

Electronics panel is designed for high visibility throughout pilothouse. Major components like electronic charts, radar and
..........depth sounder are visible to persons seated at pilothouse table.
Com-Nav 90625 1101RFC autopilot with rate stabilized fluxgate compass. Com-Nav has additional separate analog rudder
..........angle indicators in pilothouse and on flybridge. Autopilot is interfaced to GPS/Loran. Autopilot has two remote stations
..........on flybridge helm and at pilothouse guest seating. Each station may be handheld on extension cord.
Furuno FR-8050 48-mile radar with 12" CRT and 4' antenna has capability of north up operation because of interface with
..........autopilot electronic compass. With interfaces, operator has choice of true motion, relative motion, heads up, course up,
..........or north up operation. Radar is interfaced with and displays GPS, depth, heading, and AIS inputs.
Computers (minimum of 2) onboard both contain key operating software including Engine Room Log and Pilothouse Log as
..........well as Airmar weather station and satellite communications software. Computers use version 10.7 of Nobeltec Visual Navigation
..........System.
Remote computer display in pilothouse uses panel mounted 24" color LCD 1920 x 1200 monitor with speakers and video inputs.
HP 952C Hewlett Packard Deskjet color printer.
HP 4600 document Scanner
Nobeltec GPS interfaced electronic charting & navigation software (Visual Navigator Suite MaxPro Version 10.7) with electronic
..........charts from Puget Sound through the Aleutian Islands, AK. Charts include NOAA raster charts, Nobeltec vector
..........charts, NDI Charts (Canada) as well as selected aerial photos. Additional aerial photos from Google earth are stored on
..........the boats computers. Maps can be printed
Electronic charts are backed up by a full set of U. S. and Canadian government nautical paper charts covering Puget Sound to
..........Kodiak Alaska.
Nobeltec’s AIS 200 navigation transponder receiver displays location and movement of commercial vessels on the Nobeltec
..........VNS software as well as the Furuno radar.
Nobeltec’s Tides & Currents software is installed on each laptop computer(s).
Electronic current updated versions (searchable .pdf files) of U. S. Coast Pilots 7, 8, & 9 covering the West Coast of North
..........America from California through the Bering Sea are stored on computer.
Airmar Weather Station displays wind speed (apparent and true), wind direction (apparent and true), temperature, air pressure,
..........dew point, pitch & roll, compass heading, GPS satellites in view, outside temperature, wind chill, and has it’s own internal
..........GPS and electronic compass.
Furuno RD-30 Repeater with S type flush mount display (OP20-17). RD-30 displays weather information as well as
..........depth/speed/temperature/lat-lon information.
JRC 212 DGPS has its own antenna and displays through the computer system and sends NMEA 183 signals via Noland
..........N183-41 serial multiplexer.
Toggle switch on dash allows input of GPS data to computer from JRC 212 DGPS unit or alternate if installed. GPS/DGPS
..........data is combined with depth-sounder information using Noland N183-41 serial multiplexer.
Antenna hook up available for connection to a portable GPS carried onboard, if needed as backup.Panasonic PABX telephone
..........system with nine stations includes all five staterooms, galley (on wall by refrigerator), pilothouse (by console), flybridge
..........(in cabinet), and salon (aft end table).
Globalstar Satellite service through provides 24 hour direct digital voice and datacommunications from Alaska through Mexico.
..........Full Internet access (@ 9600 baud). E-mail and Internet access compression through Ocens.net software.
Fleet 33 global satellite service providing voice and full internet access @ 9600 baud.
Digital Antenna cellular 38 dB gain dual band wireless amplifier/repeater cellular antenna and amplifier system jack allows
..........amplification of cellular signals to any cell phone within 15’ of pilothouse.
BBX long range external Wi-Fi antenna enables reception of Wi-Fi signals for distances exceeding one mile allowing e-mail
..........reception and Internet access while cruising.
Furuno FCV600L 5.6" color LCD depth sounder, speed log, and temperature gauge with Furuno 525ST-MSD bronze thru hull
..........multi sensor is overhead gives depths to 1000’.
Datamarine Dart 4 system including three remotes (Two 240 displays & Two 230 displays). Remotes by master stateroom bed
..........to port, on aft deck, and at flybridge steering station. New transducers installed in 2004. Dart system gives depths to
..........400’
Beede Depth Talker talking depth sounder is interfaced to Dart depth sounder. This calls out depth changes and is very useful
..........when navigating shallow and narrow passages. It is positioned so that it can be heard on flybridge, and can also be
..........broadcast through the auxiliary function of the hailer.
Furuno Airmar 235DT-MSE Bronze thru hull smart sensor transducer provides third source of depth & water temperature information.
..........Airmar depth range is 200’.
Toggle switch on dash allows input of depth & water temperature data to computer from either Furuno FCV600L depth
..........sounder or from Furuno Airmar 235DT-MSE Bronze thru hull smart sensor triducer.. Depth & water temperature data is
..........combined with depth-sounder information using Noland N183-41 serial multiplexer.
Furuno 208A Weather fax for 24 hours weather monitoring (not currently in use).
Sea 156 VHF radio and antenna, and emergency antenna plug-in for handheld VHFs. Auxiliary earphones can be used to enhance
..........quality of weak signaled messages.
Standard LH-10 hailer with 2 horns and 4 intercoms. The two external horns are located facing fore under fly bridge overhang
..........and aft on mast on back deck. The intercoms with call back speakers are located in the forward companionway, on the
..........aft deck, the engine room, and at the fly bridge helm station. Auxiliary input is connected to Depth-talker, but can be
..........switched to the VHF radio.
Two Aetna Engineering model 8905 solid-state four digit precision digital tachometers (LED).
Lighted Ritchie 5" compass on centerline.
Oregon Scientific weather station gives interior & exterior temperatures and humidity, general weather conditions, and atomic
clock reading,.
Halogen high intensity light on dimmer switch located over chart table. Red cover available for night viewing.
Seth Thomas 5" barometer and 5" quartz clock.
Vessel is secured by electronic intrusion alarm with exterior horn on mast.

COMPANIONWAY TO FLYBRIDGE

Pilothouse vented using solar driven exhaust fan located at top of companionway.
Sliding file drawer under stairs to flybridge holds legal size hanging file folders. Also large storage closet with double 120v
..........outlet under stairs for rechargeable items.
Large storage area with access door from companionway into area above pilothouse. This is primary storage area for flares,
..........life preservers, etc.

FLYBRIDGE & ELECTRONICS

Instrumentation by engine manufacturer (see Engines).
ZF Mathers single lever dual electronic controls including built-in engine synchronizers.
Hydraulic power steering - second station.
Two Aetna Engineering model 8402 four digit precision solid-state digital LCD tachometers.
Big Bay 10.4” Outdoor High Bright Display waterproof monitor with 3 inputs and built-in mouse scalable to SVGA 1280 x
..........1024. Brightness is 100 cd/m2 (nit).
Furuno RD-30 Repeater with S type flush mount display (OP20-17). RD-30 displays depth/speed/temperature information
..........from either of two inputs as well as GPS signals from either of two inputs as selected via Noland multiplexer in pilothouse.
Remote to Datamarine Dart - 4 depthsounder/speedlog.
Remote to Com-Nav 90625 1101RFC autopilot
Remote to Wesmar Bow Thruster.
Lighted Ritchie 4" (SS2000) compass on centerline.
Two lounge seats (one bench seat to starboard and one "L" shaped bench to port) with cushion seats and fiberglass table that
..........will seat 8 for meals. Storage under both seats and console.

BOAT DECK

Large storage locker with opening lid behind seating to port of mast. Propane tanks with gauge for stove are located in storage
..........locker. System is set up with two five-gallon propane tanks with gauge plus storage of two additional five-gallon tanks
..........(full). Vent to this storage area is at lowest level of storage area. Xintex electronic shutoff to gas lines with sniffer.
14' VHF and 8' weather fax antennas extend from boat deck surface.
12' hydraulic crane by Roskolley-Olson to starboard capable of lifting 1500 pounds. Both pendant and crane are operated with
..........handheld control.
Primary shore boat is a Wooldridge 15' Alaskan aluminum jet boat (15' 6" x 6' 8" x 24"; @550 lb.) with glass windshield, electric
..........windshield wiper, seating for six, and rubber rub rails. It has a 90 HP (65 HP/JET) Evinrude engine (288 lb.) with
..........tunnel jet drive, stainless steel impeller, spare lower unit, and a twenty gallon integral aluminum fuel tank. There is a
..........Garmin 160 Blue Depthsounder with transducer and speed/temp log for jet boat. There is also an automatic bilge pump,
..........4 lockable rain proof storage compartments, Ritchie Voyager compass, electrical wiring harness, handheld VHF with
..........holder, mushroom anchor, emergency supplies and tools, handheld spotlight, 2 paddles, 1 gaff, and 2 fishing rod holders.
..........The shore boat is set as far aft on boat deck as possible (to maximize usable deck area) and across ship (to keep vessel
..........trim when shore boat is removed). The chocks are easily removable to allow substitution of alternate shore boat (15'
..........Boston Whaler) although only one can be carried onboard at a time. Jet boat can operate in 4" of water and allows exploration
..........up shallow rivers or across shallow tide flats.
Seven 10' Walden Paddlers 34 lb single person kayaks (and/or alternate brands) with double bladed paddles. Kayaks are stored
..........in custom-made rack that lowers all the kayaks at one time by crane.
OMC 8.6' 4 person white inflatable with OMC 2 HP gas engine (normally stored under bed in starboard guest stateroom).

MAST

4’ Furuno Radar antenna
Two sets of stereo speakers on mast (speaker sets face forward and aft). Separate stereo volume controls for each set of speakers
..........are located out of the weather at top of stairwell.
Four 4" X 6" 12v spreader lights facing fore (2) and aft (2).
3' AIS antenna
18” Wi-fi amplification antenna
8' cellular phone amplification antenna
2 GPS antennas
Globalstar satellite antenna
Fleet 33 satellite antenna
Airmar Weathermaster antenna
Two courtesy flag holders.
Boat has been designed so that vessel including mast and all antennas fits under the lowest of the Seattle ship canal bridges
..........(30’).

DINING AREA

U-shaped settee with 6" custom-made leather seat cushions seats six comfortably for meals. Platform under seating is 16"
..........high. Excellent visibility from this area as seating is same height as helm seats. Boat can be piloted from here as remote
..........to ComNav autopilot and remote to ZF Mathers handheld controls are located to serve this area. Also good visibility of
..........radar and instrumentation. Galley telephone is easily accessible from seating area.
Helm seats have two extra floor plates in front of dining table that allow movable helm seats to complete the seating for six at
..........dining table.
Four chart drawers in the base of the seating platform. Additional drawers in front sides of seats and under removable cushions
Hanging light box with high intensity halogen lighting on dimmer switches.
Sony stereo speakers in pilothouse ceiling with separate volume control.

GALLEY

General Electric appliances were selected throughout because of availability of parts throughout the vessel’s cruising range.
Crane double porcelain sink with Kohler Epicure single lever hot and cold water faucet w/swing spout.
General Electric four burner propane stove and self cleaning oven with broiler.
General Electric Potscrubber 900 Dishwasher w/temperature sensor, model # GSD900L-20, Serial # SD705450B
3/4 HP General Electric heavy-duty garbage disposal.
Broan trash compactor.
Amana 19+ cubic foot side by side refrigerator/freezer with exterior Ice'N Water dispenser.
Panasonic 1.1 cubic foot 1100 watt microwave under cabinet.
Remote to Xintex electronic gas snifter.
Pass through to pilothouse dining area (with removable serving tray/shelf). Good visibility aft through rear windows of vessel
..........from pilothouse and forward from galley. Mini-blinds that can be lowered for night time running.
Electric coffee maker and grinder.

SALON

Piazzetta Stufa 905 (30,000 BTU) Italian wood burning fireplace located to starboard. Stack on boat deck is easily closable
..........during summer months. Fireplace sits on granite floor.
TV/audio system cabinet with adjustable height shelves and Two 120v duplex outlets within cabinet. Control system for 5 sets
..........of remote speakers in pilothouse, salon, aft deck, and flybridge (2).
VIZIO 37" LCD flat screen HDTV in cabinet.
Sony progressive scan DVD player.
Panasonic progressive scan DVD & VCR player.
TEAC 130-watt stereo receiver with Dolby Prologic surround sound. Dolby stereo surround sound speakers & KLH 6 ½” 50
..........watt powered subwoofer.
Wired for iPod to play throughout boat through stereo receiver using keyscan iPod remote control.

MASTER STATEROOM AFT
Standard size king size walk around bed with 6" mattress and quilted cover
Removable nightstands allow access to rudders in lazarrette under swim platform.
20" color TV/DVD/VCR combination with unified single remote. 75 ohm antenna cable between TV and central antenna distribution
..........system in salon. 120v power source.
Cabinet to port side of bed has remote to Datamarine Dart system with alarm, remote start/stop to 8 kW genset, and 12v Clarion
..........AM/FM stereo, clock, and auto-reverse cassette tape deck which is hooked to central TV/FM antenna distribution
..........system. Stereo speakers are in ceiling.
Danforth lighted Tele-tale compass is located above bed with light switch in cabinet on port side of bed.
Datamarine Dart 4 system remote with alarm gives depth plus high and low water alarms in cabinet on port side of bed.
Series 1 panel (start/shutoff only) for 8 kW Northern Lights generator (M753) in cabinet on port side of bed.

MASTER HEAD

Fiberglass shower. Showerhead is removable so it can also be handheld. Shower door is bi-fold glass. Built in seat, soap
..........holder, and removable clothesline.
Vanity with Kohler porcelain sink and storage. Faucet set is Epic brass with ebony handles. Plastic laminate top with oak
..........trim. Three way adjustable mirrored storage cabinets.
Vacuflush toilet (see Waste Management).

AFT COMPANIONWAY & PASSAGE

General Electric full size side by side washer and 220-volt dryer in cabinet in aft companionway hidden behind bifold louvered
..........doors.
Half-height 4.5 cubic foot freezer sits on shelf above dryer.
Storage compartment under stairs contains water separators for both gensets, isolation transformer, 12v electrical panel, and
..........both main battery banks, plus extra storage for lines, large tools, etc.

GUEST STATEROOMS FORWARD (IDENTICAL PORT AND STARBOARD EACH)

Queen mattress and cover. Entire bed mattress/bedding can be lifted to gain access to interior storage area in center of bed plus
..........storage drawers at base of bed.
Oak dresser and night stand with drawers. Top is inlaid with mahogany and bird's-eye maple. 12v Clarion AM/FM stereo,
..........clock, and auto-reverse cassette tape deck and stereo is hooked to central TV/FM antenna and is recessed in cabinet on
..........inside side of bed. Stereo speakers are in ceiling above bed.
One 9" x 22" Freeman Marine elliptical portlight (and alternative escape hatch) with screen and mini-blinds.
Cabinet enclosure for TV/VCR set with oak tambour sliding door. One stateroom has Emerson 20" color TV/VCR combination
..........with unified single remote, and the other stateroom has a similar unit except it is a TV/DVD combination. 75 Ohm
..........cable run between TV/VCR shelf and main stereo cabinet in salon.

GUEST HEADS (THREE)

Vanity with Kohler porcelain sink and storage. Faucet set is Epic brass with ebony handles. Plastic laminate top with oak
..........trim. Mirrored storage cabinets.
Vacuflush toilet (see Waste Management).
Fiberglass shower. Showerhead is removable so it can also be handheld. Shower door is bi-fold glass. Built in seat, soap
..........holder, and removable clothesline.

FIFTH (CREW) STATEROOM

Single bed with 4" mattress has hanging locker and storage compartments under.
Drawers and door into storage area under steps. Single porthole.
Fold down desk.

BOW (FORWARD) STATEROOM

Four single bed mattresses in V-berths and bunks. Two portholes and hatch.

DECKS (GENERAL)

Full walk-around non-skid fiberglass deck.
Twelve (12) 12-volt halogen deck lights are flush mounted.
Eleven large hawse pipes (9 with 21" horns).

AFT (LOUNGE) DECK

Sink with hot & cold fresh water plus salt and hot & cold fresh water hose bibs located inside of the base of cabinet to starboard
..........under ladder to fly bridge.
Propane gas grill with gauge is located in top of cabinet to starboard under aluminum cover. Five gallon propane tank adjacent
..........with venting in cabinet where propane is stored.
1 - 4" X 6" 12v spreader light facing aft.
Remote to Datamarine Dart system with alarm visible from aft deck and swim/fishing platform.

SWIM/FISHING PLATFORM

Swim platform is 42" extension from transom and integrated as an extension of hull giving better vessel performance because
..........of longer water line.
Removable stainless staple rails with connecting safety lines
10" stainless steel cleat with open base on centerline at aft of swim platform.
26.2 gallon (99.1 liters) #5052 aluminum fuel tank (.188 cm) for gasoline located in swim grid allows easy transfer of fuel to
..........shore boats.

ANCHOR

Maxwell 2200 lb. hydraulic horizontal anchor windlass that handles both chain and line with manual backup. Power up and
..........down using foot switches on bow with remotes in pilothouse and on fly bridge.
Anchor is Bruce #110. Anchor chain is 350 ft. of 3/8" high tensile galvanized chain connected to 200' of 3/4" three strand nylon
..........line that sets on a separate shelf so line stays dry.
Backup anchor: 66 lb. Fjordford anchor. Additional sections of 35’ of chain plus 200' of 5/8” line & 18' of chain plus 200' of
..........5/8” line.
Storage areas at forward side of bow stateroom in trunk cabin forward of pilothouse to provide storage for fenders with access
..........hatch from foredeck. In addition, hose storage and hose bibs for fresh & sea water are located in an adjacent forward
..........starboard compartment.

SAFETY AND MISCELLANEOUS

Phillips Heartstart AED Home defibrillator
Extensive First Aid Supplies
Trumpet air horn, driven by its own 12v compressor, is operable from pilothouse and fly bridge.
Three hand held fire extinguishers - ABC 050 NV extinguishers Black Flag.
Two hand held fire extinguishers .
One fire extinguisher - PSH - 10 - 4 H2O.
USCG approved flare kit with extras.
40 USCG approved life preservers.
8 USCG approved survival suits
